Connection/Installation
101English
Ñ Connecting an Android
smartphone
● DDX9020DABS / DDX920WDABS /
DMX8520DABS
Micro USB to USB cable
[2]
Android smartphone (with
Android Auto)
[2]
USB (Gray) terminal
[1] [4]
USB (Black) terminal
[1]
Accessory 2 (Black) (1 m)
[3]
Accessory 3 (Gray) (1 m)
[3]
Micro USB to USB cable
[2]
● Except DDX9020DABS / DDX920WDABS /
DMX8520DABS
Micro USB to USB cable
[2]
Android smartphone (with
Android Auto)
[2]
USB (Black) terminal
[1]
Accessory 2 (Black) (1 m)
[3]
[1]
USB maximum power supply current :
DC 5 V = 1.5 A
[2]
Sold separately
[3]
See Securing the USB extension cable
(P.100).
[4]
USB (Gray) terminal does not support USB
Mirroring.
