Kenwood MDX-F1 User Manual

MDX-F1 (EN)
14
Operation
Playback of CD
Contents
Skipping tracks
To skip backward To skip forward
÷ The track in the direction of the key pressed is
skipped, and the selected track will be played from the
beginning.
÷ When the 4 key is pressed once during playback, the
track being played will be played from the beginning.
÷ Operation also is possible with the keys 4 and ¢
of the remote control unit.
Playback from desired track
Press the numeric keys as shown below....
To select track No. 23 : 003
To select track No. 40 : 0000)
Select the desired track No.
÷ Each press pauses and plays the CD alternately.
To pause playback
To stop playback
To fast forward and backward
(Remote control unit only)
÷ Playback starts from the position where the key is
released.
Backward
search
Forward
search
CD
6
7
STOP
¢
4
123
456
789
+10 0
Time display on CD player
(Remote control unit only)
Each press of the TIME DISPLAY key changes
the displayed contents.
÷ Only time information 1 and 2 can be displayed
during repeats playback or random playback.
1
2
3
4
(Remaining time of track being
played)
(Elapsed time of entire disc)
(Elapsed time of track being played)
(Remaining time on entire disc)
1 1 TUNING
123
-237
TOTAL
2345
TOTAL
-3615
TIME
DISPLAY
Ejecting the disc
P
U
S
H
O
P
E
N
0
÷ Press the key before making sure that the disc is
stopped.
÷ If the “PGM” indicator is lit, stop the CD recorder and
press the PGM key of the remote control unit to turn
the indicator off.

Kenwood MDX-F1 Specifications

Amplifier Section

rated output power during STEREO operation	4 W + 4 W
speaker unit	80 mm, cone type

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
MW (AM) tuning frequency range	531 kHz ~ 1, 602 kHz

General Specifications

power consumption	38 W
standby power consumption	0.3 W
dimensions (W x H x D)	464 mm x 182 mm x 243 mm
weight (net)	5.4 kg
