CFS/CCS-BA-e-1013 43
15.1 Technical Data
Connector 9 pin d-sub bushing
Pin 2 output
Pin 3 input
Pin 5 signal earth
Baud rate
600/1200/2400/4800/9600
Parity
8 bits, no parity / 7 bits, even parity / 7 bits, odd parity
bold printed = factory setting
15.2 Remote control instructions
All inputs finish with <CR><LF> (carriage return / line feed).
At wrong inputs the command will be preceded by "ER", e.g. order "NN<CR><LF>",
error message "ER NN<CR><LF>".
15.2.1 Control commands
PLU
xx
Call-up PLU from data memory
T Tare placed weighing vessel
T123.456 Numeric tare value
Z Zeroing
P Print
M+ Add and print weighing data in the summation memory
MR Call-up data from memory
MC Delete memory
U123.456 Save the average piece weight 123.456 [g] or [lb]
S123 Input number of pieces e.g. 123 pieces
SL Reference balance
SR Bulk material balance
