KERN CFS Operating Manual

8 bits, no parity
7 bits, even parity
7 bits, odd parity
Standard printer setting
Not documented
Shows the current user identification number,
max. 6 characters, input see chpt. 11.3.1
Shows the current balance identification number,
max. 6 characters, input see chpt. 11.3.1
Details
see chpt. 13
password-protected
13 Configuration bulk material balance / technical parameters
 Changes should only be carried out by trained specialized personnel.
 Navigation in menu see chpt. 12.1
In factory the balance KERN CFS or the counting system KERN CCS are precon-
figured in a way that normally no more changes will be necessary.
But if there are special conditions of use or if as bulk material balance an other
weighing bridge (not preconfigured by KERN) is connected, in the menu block
"
" the required settings can be made.
Technical data:
Supply voltage 5 VDC
Max. signal voltage 0-20 mV
Zeroing range 0-5 mv
Sensitivity > 0.02 μv
Resistance parameter 87 Ω Min., 4 x 350 Ω load cell
Connector 4 poles
Max. cable length 6 meter
Connection plug 9 pin d-subminiature bushing
38 CFS/CCS-BA-e-1013

KERN CFS Specifications

General

Plate material	stainless steel
Readability	0.01 g
Reproducibility	0.01g
Calibration	External calibration
Display	LCD
Weighing units	g, lb, oz
Operating temperature	10 °C - 40 °C
Functions	counting, weighing
Interface	RS-232
