CIB-BA-e-2010 7
2.1.2 Display reference weight
The reference weight of a sample is shown here. This value is either entered by user
or calculated by the balance.
The overlay
indicates:
Placed reference weight insufficient for reference calculation
Placed number of pieces insufficient for reference calculation/
Stability display
2.1.3 Display piece quantity
Here, all the parts placed on balance are immediately displayed by number.
The overlay
indicates:
Memory locations 01-10
Memory locations 11-20
Data in sum memory
2.1.4 Power supply unit display
green
If the LED next to this symbol glows green, the power
supply unit is correctly connected and the rechargeable
battery is being charged.
