KERN FCB Operating Instructions

4 TFCB-A_TFCB-B-BA-def-2313
English
1 Technical data
KERN
FCB 6K-5
FCB 12K-4
FCB 30K-4
Item no./ Type
TFCB 6K-5-A
TFCB 12K-4-A
TFCB 30K-4-A
Readability (d)
0,05 g
0,1 g
0,2 g
Weighing range (max)
6.000 g
12 kg
30 kg
Reproducibility
0,05 g
0,1 g
0,2 g
Linearity
± 0,15 g
± 0,3 g
± 0,6 g
Stabilization time (typical)
2 s
Smallest part weight for
piece counting - under lab
conditions*
50 mg
100 mg
200 mg
Smallest part weight for
piece counting - under
normal conditions**
500 mg
1 g
2 g
Adjustment points
2 kg / 4 kg / 6 kg
2 kg / 5 kg / 10 kg / 12 kg
10 kg / 20 kg / 30 kg
Recommended adjust-
ment weight, not added
(class)
6 kg (F2)
12 kg (F2)
20 kg (F1) / 10 kg (F1)
Warm-up time
2 h
Weighing Units
g, kg, lb, gn, dwt, oz, ozt, pcs, FFA, %
Humidity of air
max. 80% rel. (non-condensing)
Allowable ambient tempe-
rature
0 °C ... + 40 °C
Input voltage Appliance
5,9 V, 1 A
Input voltage Mains adapter
100 V - 240 V AC; 50 / 60 Hz;
Storage battery operation
(optional)
Operating time 48 hrs (backlight off)
Operating time 24 hrs (backlight on)
Loading time approx. 8 hrs.
Auto-Off (battery, re-
chargeable battery)
selectable off, 30s, 1, 2, 30, 60 min
Dimensions housing
322 x 267 x 103 (W x D x H) [mm]
Weighing plate, stainless
steel
252 x 225 (W x D) [mm]
Net weight (kg)
3,25
Interfaces
RS-232 (optional), Ethernet (optional), Bluetooth BLE (v4.0) (optional),
USB-Device (optional), WiFi (optional) via KUP
