Save/Recall (Setups, Screens, Data) 18
Keysight InfiniiVision 2000 X-Series Oscilloscopes User's Guide 237
When available, the Increment softkey can be used to enable or disable
automatically incremented file names. Auto increment adds a numeric suffix to
your file name and increments the number with each successive save. It will
truncate characters as necessary when the file name length is at maximum and
more digits are required for the numeric portion of the file name.
Recalling Setups, Masks, or Reference Waveforms
1 Press the [Save/Recall] key.
2 In the Save/Recall Menu, press Recall.
3 In the Recall Menu, press Recall:, then, turn the Entry knob to select the type of
file you want to recall:
• Setup (*.scp) — See “To recall setup files" on page 237.
• Mask (*.msk) — See “To recall mask files" on page 238.
• Reference Waveform data (*.h5) — See “To recall reference waveform files from
a USB storage device" on page 238.
You can also recall setups and mask files by loading them using the File Explorer.
See “File Explorer" on page 251.
You can also configure the [Quick Action] key to recall setups, masks, or reference
waveforms. See “Configuring the [Quick Action] Key" on page 262.
To recall setup files
Setup files can be recalled from one of 10 internal (\Keysight Flash) locations or
from an external USB storage device.
1 Press [Save/Recall] > Recall > Recall:; then, turn the Entry knob to select Setup
(*.scp).
2 Press the softkey in the second position and use the Entry knob to navigate to
the file to recall. See “To navigate storage locations" on page 236.
3 Press the Press to Recall softkey.
You can use a connected USB keyboard instead of using the Spell (and other) character
editing softkeys.
