Keysight InfiniiVision 2000 X-Series Oscilloscopes

User's Guide

23 CAN/LIN Triggering and

Serial Decode

Setup for CAN Signals / 301

CAN Triggering / 303

CAN Serial Decode / 305

Setup for LIN Signals / 309

LIN Triggering / 311

LIN Serial Decode / 312

CAN/LIN triggering and serial decode requires Option AUTO or the DSOX3AUTO

upgrade.

Setup for CAN Signals

Setup consists of connecting the oscilloscope to a CAN signal, using the Signals

Menu to specify the signal source, threshold voltage level, baud rate, and sample

point.

To set up the oscilloscope to capture CAN signals, use the Signals softkey which

appears in the Serial Decode Menu:

1 Press [Label] to turn on labels.

2 Press [Serial].

3 Press the Mode softkey; then, select CAN trigger type.

4 Press the Signals softkey to open the CAN Signals Menu.
