60 Keysight InfiniiVision 2000 X-Series Oscilloscopes User's Guide
2 Horizontal Controls
To navigate search events
When acquisitions are stopped, you can use the navigation controls to go to found
search events (set using the [Search] key and menu, see “Searching for Events" on
page 58).
1 Press [Navigate].
2 In the Navigate Menu, press Navigate; then, select Search.
3 Press the back and forward keys to go to the previous or next search
event.
When searching Serial decode:
• You can press the stop key to set or clear a mark.
•The Auto zoom softkey specifies whether the waveform display is automatically
zoomed to fit the marked row as you navigate.
• Pressing the Scroll Lister softkey lets you use the Entry knob to scroll through
data rows in the Lister display.
To navigate segments
When the segmented memory acquisition is enabled and acquisitions are stopped,
you can use the navigation controls to play through the acquired segments.
1 Press [Navigate].
2 In the Navigate Menu, press Navigate; then, select Segments.
3 Press Play Mode; then, select:
• Manual — to play through segments manually.
In the Manual play mode:
• Press the back and forward keys to go to the previous or next
segment.
• Press the softkey to go to the first segment.
• Press the softkey to go to the last segment.
• Auto — to play through segments in an automated fashion.
In the Auto play mode:
