Function Specific Troubleshooting
If the E5061B exhibits a failure symptom that is related to a specific function or
control such as a front panel key control, display, data storage, remote control
interface, printer interface, external trigger, external keyboard or mouse,
isolate the trouble using the Function Specific Troubleshooting procedures
described below. The major functions of the E5061B and the troubleshooting
procedure for each function are shown in Table 2-5.
Table 2-5 Major functions and troubleshooting procedures
Function Description Troubleshooting
Front panel keys All the E5061B functions except for VBA and
service functions can be set and controlled via the
front panel keys.
Refer to “To Check the
Front Panel” on
page 42.
Touch panel The E5061B equipped with option 016 has a
touch screen display that allows all the functions
in the menu bars, setup windows and dialog
boxes to be set by a touch to the screen panel.
Refer to “To Check the
Touch Panel” on
page 42.
LCD display Almost all the information including the
measurement value, setup state, result data
processing, menu bar, softkey label and others
are indicated on the 10.4-inch color LCD display.
Refer to “To Check the
LCD” on page 43.
External keyboard The external keyboard can be used for the entry of
numerical and character data when it is
connected to USB connector on front and rear
panels.
Refer to “To Check the
External Keyboard” on
page 43.
Mouse The mouse can be used to move the pointer on
the LCD display, select a function and change a
setting, when it is connected to USB connector on
front and rear panels.
Refer to “To Check the
Mouse” on page 43.
Video output An external color monitor can be used to display
the same information as the E5061B LCD display,
when it is connected to the Video output
connector (24-pin D-Sub) on the rear panel.
Refer to “To Check the
Video output” on
page 44.
External trigger input The external trigger input terminal (BNC) on the
rear panel allows an external trigger source to be
used for measurement trigger.
Refer to “To Check the
External Trigger Input”
on page 44.
GPIB Interface The GPIB compatibility allows the E5061B to be
operated as a talker/listener on IEEE 488
interface bus.
Refer to “To Check the
GPIB” on page 44.
Handler I/O port The Handler I/O port can be used to transfer a
comparator decision output data to and perform
timing synchronization with an external handler.
Refer to in “To Execute
the Diagnostic Test” on
page 33 .
