Keysight E5061B Network Analyzers 33
Troubleshooting
Troubleshooting Using Diagnostic Test
Test equipment required for diagnostic test
Table 2-2 shows the equipment required for performing the diagnostic test.
To Execute the Diagnostic Test
To isolate faulty board assembly in analog section, execute the diagnostic test
in accordance with the following procedure. The test procedure needs to be
performed using a mouse and an external keyboard in addition to the front
panel keys.
Step 1. Connect a mouse and an external keyboard to the E5061B’s rear panel
connector.
Step 2. Press key.
Step 3. Press Load Project to select Load Project function. "Open" dialog box will be
displayed as shown in Figure 2-13.
7 Receiver IF Ranging Test
8 Gain-Phase Absolute Measurement Test
(Option 3L5)
Table 2-1 Diagnostic test group menu
Table 2-2 Required equipment
Required test equipment Qty Recommended model
24 inch 50 cable 1 8120-8862, 8120-1839
To perform the diagnostic test properly, the following conditions must be
met:
Environmental temperature: 23 ºC ± 5 ºC
Do not operate front panel keys, keyboard and mouse during the
diagnostic test. Changing the instrument settings while the diagnostic test
is in progress will cause incorrect test results.
