104 Keysight E5061B Network Analyzers
Post-Repair Procedures
Post-Repair Procedures
5-
Post-Repair Procedures
Table 5-1 Post Repair Procedures lists the required procedures that must be
performed after the replacement of an assembly. These are the recommended
minimum procedures to ensure that the replacement is successfully
completed.
Table 5-1 Post-Repair Procedures (Option 3L5)
Replaced
Assembly or Part
Required Adjustments
Correction Constants (CC)
Verification
A1 Source
Module
Perform the following required
adjustments using “A1 Source Module” in
Spot Adjustment of the program.
“To Execute the Diagnostic Test” on
page 33
Frequency Accuracy Test
RF Output Level Accuracy and Flatness Test
RF Output Level Linearity Test
Trace Noise Test
Crosstalk & System Dynamic Range Test
Dynamic Accuracy Test
Uncorrected System Performance Test
LF Output Level Accuracy Test (Opt 3L5)
LF Output Level Linearity Test (Opt 3L5)
Input Impedance Test (Opt 3L5)
Absolute Amplitude Accuracy Test (Opt 3L5)
Magnitude Ratio/Phase Frequency
Response Test (Opt 3L5)
Trace Noise Test (Opt 3L5)
Crosstalk and Noise Level Test (Opt 3L5)
Magnitude Ratio/Phase Dynamic Accuracy
Test (Opt 3L5)
To Next Page
