Troubleshooting
Troubleshooting Using Diagnostic Test
Program Overall
Instrument
Information The option and serial number for the E5061B, and test date
can be entered automatically.
Test Conditions The test conditions, “Temperature”, “Humidity” and person
doing the test (“Tested by”) can be entered.
Test Items The following test can be selected. To execute the test you
select, click “Execute” button.
•DC-BUS Test
• Internal Level Monitor Test
•RF Output Level Range Test
• RF Output Level Power SweepTest
• Receiver Absolute Measurement Test
• Receiver Compression Test (Option 3L5 only)
•Receiver IF Ranging Test
• Gain-Phase Absolute Measurement Test (option 3L5 only)
When each test is executed, the test dialog box is displayed.
The following screen is an example of the test dialog box.
Figure 2-15 Test dialog box
To execute the test, click “Execute” button. To return the
E5061B Diagnostic test program dialog box (Main Menu),
click “Back to Main Menu”.
The test program will prompt you to connect cables or Short
termination to the E5061B. Follow the instructions as shown
below on the E5061B display for performing the test.
