282 Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide
Replacement Parts
Assemblies, Cables, and Hardware
A6MP7, Display Side Support W1312-20216
A6MP8, RFI Gasket, Front Frame 8160-0660
A7 Real Time BBG Assembly
N5172B, N5182B, Option 660 only
N5180-60429
A7A1 Real Time Aux Power Supply
N5172B, N5182B, Option 660
N5180-60430
A7A1MP1 Real Time BBG Aux Power Supply Cover
N5172B, N5182B, Option 660
N5180-60431
A7 Micro-Deck Assembly (N5173B, N5183B)
Option 513, 520 Front Panel Output New
Exchange
N5180-60460
N5180-69460
Option 532, 540 Front Panel Output New
Exchange
N5180-60463
N5180-69463
Option 1EM, Type-N Output Connector New
Exchange
N5180-60462
N5180-69462
Option 1EM, 3.5 mm Output Connector New
Exchange
N5180-60461
N5180-69461
Option 1EM, 2.4 mm Output Connector New
Exchange
N5180-60464
N5180-69464
A7A3A1 50 ohm Termination, Option 513, 520 1810-0118
A8 Real Time BBG Jumper Board
N5172B, N5182B, Option 660
N5180-60432
A8 BNC Bypass Board
N5173B, N5183B
E8251-63665
B1 thru B4 Fan Assembly (each) N5180-60433
J1 Front Panel RF Output Connector
Type-N Female
3.5 mm Female
2.4 mm Female
1250-3968
08673-60040
5063-1700
Front Panel RF Output Connector Bracket
Type-N Output Connector
3.5 mm Output Connector
2.4 mm Output Connector
N5180-20114
N5180-20115
N5180-20116
Table 14-1 Assemblies, Chassis, and Cables
Description Part Number
