Keysight Technologies N5172B EXG Service Guide

Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide 283
Replacement Parts
Assemblies, Cables, and Hardware
Front Panel RF Output Connector Spacer
Type-N Output Connector
3.5 mm Output Connector
2.4 mm Output Connector
N5180-20056
E8251-20068
None
J1 Rear Panel RF Output Connector
Type-N Female
3.5 mm Female
2.4 mm Female
1250-3968
08673-60040
5063-1700
Rear Panel RF Output Connector Adapter (N5173B, N5183B)
Type-N Output Connector
3.5 mm Output Connector
2.4 mm Output Connector
N5180-20062
N5180-20061
N5180-20060
Rear Panel RF Output Connector Spacer
Type-N Output Connector
3.5 mm Output Connector
2.4 mm Output Connector
N5180-20056
E8251-20068
None
Rear Panel LO IN Connector (Option 012) 1250-1666
Rear Panel LO OUT Connector (Option 012) 1250-1666
Rear Panel DAC CLK IN Connector (Option 012) 1250-1666
Main Chassis W1312-00125
Rear Panel
N5171B, N5181B
N5166B, N5172B, N5182B
N5173B, N5183B
N5180-00020
N5180-00019
N5180-00018
Chassis Inside Top Cover W1312-00126
Chassis Inside Bottom Cover W1312-00127
Rear Panel SD Memory Card Cover (Option 006) N5180-00027
RFI Gasket, LCD 8160-1801
Chassis Corner Nuts W1312-20038
Table 14-1 Assemblies, Chassis, and Cables
Description Part Number
