50 Keysight Agile Signal Generator Service Guide
Troubleshooting
Table 1-4 Device Output Power - 40 GHz Models
Output Frequency (GHz)
≥ .01 to < 1.43 ≥ 1.43 to < 2.85 ≥ 2.85 to < 5.70 ≥ 5.70 to < 11.4
≥ 11.4 to <22.8 > 22.8 to <40.0
N
Multiplier
1 2 4 8 16 32
A19
Output
Frequency ≥ .01 to < 1.43 ≥ 1.43 to < 2.85 ≥ 2.85 to < 5.7 ≥ 5.7 to < 11.4 ≥ 11.4 to <
22.8 >22.8 to < 40
Power > 15.5 dBm > 18.5 dBm > 18.0 dBm > 18.0 dBm > 17.0 dBm > 19 dBm
A18J4
Frequency ≥ .01 to < 1.43 ≥ 1.43 to < 2.85N/AN/AN/AN/A
Power > 17 dBm > 20 dBm N/A N/A N/A N/A
A17J2
Frequency N/A ≥ 1.43 to < 2.85N/AN/AN/AN/A
Power N/A > 8.5 dBm N/A N/A N/A N/A
A17J4
Frequency N/A N/A N/A N/A N/A >10.275 to <
20
Power N/A N/A N/A N/A N/A > 20 dBm
A16J4
Frequency N/A ≥ 1.43 to < 2.85 ≥ 2.85 to < 5.7 N/A N/A N/A
Power N/A > 15 dBm > 16 dBm N/A N/A N/A
A16J10
Frequency N/A N/A N/A > 5.7 to < 11.4 ≥ 11.4 to <
22.8 > 11.4 to < 20
Power N/A N/A N/A > 2.0 dBm > 4.0 dBm > 20 dBm
A14J2
Frequency N/A ≥ 0.715 to
< 1.425
≥ 0.7125 to
< 1.425
≥ 0.7125 to
< 1.425
≥ 0.7125 to
< 1.425
≥ 0.7125 to <
1.25
Power N/A > 3.0 dBm > 3.0 dBm > 3.0 dBm > 3.0 dBm > 3.0 dBm
A14J1
Frequency < 1.43 N/A N/A N/A N/A N/A
Power > 10 dBmN/AN/AN/AN/AN/A
