Keysight N5991 Test Automation Software Platform Getting Started Guide 51
Using the Software 5
Incomplete-Imported. It indicates that the imported procedure was aborted/disturbed somehow
and failed
Incomplete-Iterative. It indicates that the procedure was run for several repetitions and they were
incomplete.
Additional States
CalMissing. This icon appears on the right-bottom corner of the main icon.
For example:
It is specific for calibration procedures. It indicates that the calibration data is missing, and
therefore is not available to be used in the Rx tests.
Offline. This icon appears on the right-top corner of the main icon.
For example:
It indicates that the procedure has been run (or will be run) in offline mode.
Both states can happen at the same time. For example:
It indicates that the calibration was run offline and that the offline calibration data is not available.
Icon Description
