Repair Guide 6
Keysight N8262A Service Guide 97
– Remove the power reference input connector
(see the figure to the right):
– Use the 19 mm socket to remove the nut on
the power reference input connector on the
front panel.
Use a T20 Torx screwdriver bit to remove the
four screws (located at both side of the front
panel), which holds the front frame to the
chassis.
Instructions Visual
