Keysight Infiniium MSOS404A Service Guide

44 S-Series Oscilloscopes Service Guide
3 Testing Performance
Performance Test Record
Keysight Technologies
Keysight Infiniium S-Series Oscilloscopes
Model Number ___________________________ Tested by_______________________
Serial Number ____________________________ Work Order No.___________________
Recommended Test Interval—1 Year/2000 hours Date___________________________
Recommended next test date _________________ Ambient temperature ______________
Input Impedance Test
Input
Resistance
Vertical Scale Channel 1 Channel 2 Channel 3 Channel 4 Limits
50 Ω 5 mV/div 48.25 Ω to 51.75 Ω
50 Ω 10 mV/div 48.25 Ω to 51.75 Ω
50 Ω 20 mV/div 48.25 Ω to 51.75 Ω
50 Ω 50 mV/div 48.25 Ω to 51.75 Ω
50 Ω 100 mV/div 48.25 Ω to 51.75 Ω
50 Ω 200 mV/div 48.25 Ω to 51.75 Ω
50 Ω 500 mV/div 48.25 Ω to 51.75 Ω
50 Ω 1 V/div 48.25 Ω to 51.75 Ω
1 MΩ 5 mV/div 990 kΩ to 1.010 MΩ
1 MΩ 10 mV/div 990 kΩ to 1.010 MΩ
1 MΩ 20 mV/div 990 kΩ to 1.010 MΩ
1 MΩ 50 mV/div 990 kΩ to 1.010 MΩ
1 MΩ 100 mV/div 990 kΩ to 1.010 MΩ
1 MΩ 200 mV/div 990 kΩ to 1.010 MΩ
1 MΩ 500 mV/div 990 kΩ to 1.010 MΩ
1 MΩ 1 V/div 990 kΩ to 1.010 MΩ
1 MΩ 2 V/div 990 kΩ
to 1.010 MΩ
1 MΩ 5 V/div 990 kΩ to 1.010 MΩ
