Replaceable Parts
Hardware
Table 14-23 Front Frame Exploded View
Item Description Keysight Part Number
1 RPG Knob W1312-40179
2 Overlay, Keyboard N9020-80127
3 Front Frame Side Trim Strip (plastic, 2 ea) N9020-40018
4 Cover Plate N9020-00002
5 Front Frame
---
a
6 A1A5 Main Keypad N9020-40001
7 Display Boot N9020-40002
8 EMI Gasket
---
a
9 A1A4 Keyboard, PCA N9020-63294
10 A1A2 Front Panel Control Board N9020-63274
11 A1A3 Liquid Crystal Display 10.6-in w/PCAP Touch
1280X768-Pixels
2090-1103
12 A1MP9 Display hold down (compression pad) N9020-40003
13 A1MP11 Display Bracket, Front Panel N9020-00078
14 A1MP10 Bracket front panel shield N9020-00064
15 A1W1 Flex Circuit, Display to Front Panel Control Board N9020-60273
16 A1W2 Cable Assembly, Backlight N9020-60217
17 A1MP14 Shield N9020-00066
18 W1 Cable, Front Panel Interface Board to Motherboard
(Ribbon)
N9020-60216
a. Non-orderable item, see A1A1.
