Keysight N9010B EXA Signal Analyzer Service Guide 537
Assembly Replacement Procedures
Front Frame Assembly
Table 15-4
Item Description
1RPG Knob
2 Overlay, Keyboard
3 Front Frame Side Trim Strip (plastic, 2 ea)
4Cover Plate
5 Front Frame
6
A1A5
Main Keypad
7 Braided Gasket
8 EMI Gasket
9 A1A4 Keyboard, PCA
10
A1A2
Front Panel Control Board
11
A1A3
Liquid Crystal Display 10.6-in w/PCAP Touch
1280X768-Pixels
12
A1MP9
Display hold down (compression pad)
13 A1MP11 Display Bracket, Front Panel
14
A1MP10
Bracket front panel shield
15 A1W1 Flex Circuit, Display to Front Panel Control Board
16 A1W2 Cable Assembly, Backlight
17 A1MP14 Shield
18 W1 Cable, Front Panel Interface Board to Motherboard (Ribbon)
