3 Spectrum Analyzer Mode
3.8 Spurious Emissions Measurement
n Return Value
<Marker Number>,<Marker Trace>,<X>,<Y>,<Reserved>,<Reserved>
Only markers that are enabled are included. <Reserved> items are returned as SCPI_NAN
The data is returned in the current sort order as displayed in the Marker Table
3.8.1 Views
This measurement has two predefined views:
# Name SCPI
1 "Graph + Metrics" on page 1411
RESult
2 "All Ranges" on page 1411
ALL
These are multiple-window views. When in a multiple-window view, you select a
window by touching it. The menu controls may sometimes change, depending on
which window is selected.
Remote Command
:DISPlay:SPURious:VIEW[:SELect] RESult | ALL
:DISPlay:SPURious:VIEW[:SELect]?
Example
:DISP:SPUR:VIEW RANG
:DISP:SPUR:VIEW?
Preset
RESult
State Saved No
Range Graph + Metrics | All Ranges
3.8.1.1 Graph + Metrics
Windows: "Graph" on page 1355,"Table" on page 1356
Select Graph + Metrics to view measurement results.
–
The upper window displays a trace of the range that contains the currently
selected spur
–
The lower window displays a list of spurs detected in a measurement cycle. The
currently selected spur, which is highlighted, can be changed by the Spur
control in the Meas Setup menu
Example
:DISP:SPUR:VIEW RES
1354 Spectrum Analyzer Mode User's &Programmer's Reference
