Keysight N9030B - Sync Segment 2; Segment 2 Frequency

6 Input/Output
6.1 RF Source
–
xxx0_1.wfm for TRX1
–
xxx0_2.wfm for TRX2
–
xxx1_0.wfm for TRX3
–
xxx1_1.wfm for TRX4
xxx1_2.wfm for TRX5
Preset
OFF
Range
ON|OFF
Sync Segment 2
Lets you config the models in the second group of NxN+NxN MIMO.
Remote Command
:SOURce:SYNC:SETTings:SEGMent2:ENABle ON | OFF | 1 | 0
:SOURce:SYNC:SETTings:SEGMent2:ENABle?
Example
:SOUR:SYNC:SETT:SEGM2:ENAB ON
:SOUR:SYNC:SETT:SEGM2:ENAB?
Notes Only Frequency in settings is supported
Dependencies When this setting is ON, Sync Settings will be turned on accordingly
Preset
OFF
Range
ON|OFF
Segment 2 Frequency
When Sync Segment 2 is ON, allows you to set the frequency of models in the
second group of NxN+NxN MIMO.
Remote
Command
:SOURce:SYNC:SETTings:SEGMent2:FREQuency <freq>
:SOURce:SYNC:SETTings:SEGMent2:FREQuency?
Example
:SOUR:SYNC:SETT:SEGM2:FREQ 1.00 GHz
:SOUR:SYNC:SETT:SEGM2:FREQ?
Preset 1.00 GHz
Min VXT models M9410A/11A/15A/16A: 380 MHz
Max Hardware Dependent
VXT models M9410A/11A/15A/16A:
–
Option F06 = 6.0 GHz
Spectrum Analyzer Mode User's &Programmer's Reference 2327
