Keysight N9030B - PSD Unit; IF Gain

3 Spectrum Analyzer Mode
3.3 Channel Power Measurement
Mode Radio Std Integ BW
WLAN 802.11a/g(OFDM/DSSS-OFDM) 20 MHz
802.11b 25 MHz
802.11n/ac/ax/be (20MHz) 20 MHz
802.11n/ac/ax/be (40MHz) 40 MHz
802.11n/ac/ax/be (80MHz) 80 MHz
802.11ax/be (80 MHz + 80 MHz) 80 MHz
802.11ac/ax/be (160 MHz) 160 MHz
802.11be (160 MHz + 160MHz) 160 MHz
802.11be (320MHz) 320 MHz
State Saved Saved in instrument state
Min/Max 100 Hz / Hardware Maximum Span
Backwards
Compatibility SCPI
[:SENSe]:CHPower:BWIDth:INTegration
PSD Unit
Sets the unit bandwidth for Power Spectral Density. The available units are dBm/Hz
(DBMHZ) and dBm/MHz (DBMMHZ).
Remote
Command
:UNIT:CHPower:POWer:PSD DBMHZ | DBMMHZ
:UNIT:CHPower:POWer:PSD?
Example
:UNIT:CHP:POW:PSD DBMMHZ
:UNIT:CHP:POW:PSD?
Couplings When the PSD unit is changed, the response to :MEAS|READ|FETCH:CHP1? also changes by the
PSD unit basis (either dBm/Hz or dBm/MHz)
Preset WLAN mode or SA mode with WLAN radio standard: DBMMHZ
Otherwise: DBMHZ
State Saved Saved in instrument state
Range dBm/Hz | dBm/MHz
IF Gain
Sets IF Gain to Auto, Low Gain or High Gain. These settings affect sensitivity and IF
overloads.
Remote Command
[:SENSe]:CHPower:IF:GAIN[:STATe] ON | OFF | 1 | 0
642 Spectrum Analyzer Mode User's &Programmer's Reference
