3 Spectrum Analyzer Mode
3.9 SEM Measurement
Radio Std Presets
802.11ac/ax (80MHz/160MHz) -69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm,
-69.00 dBm,-69.00 dBm, -69.00 dBm, -69.00 dBm,-69.00 dBm, -
69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm
802.11be
(80MHz/160MHz/320MHz)
-49.00 dBm, -49.00 dBm, -49.00 dBm, -49.00 dBm, -49.00 dBm,
-49.00 dBm, -49.00 dBm, -49.00 dBm, -49.00 dBm, -49.00 dBm,
-49.00 dBm, -49.00 dBm, -49.00 dBm, -49.00 dBm
802.11ac/ax (80 + 80 MHz) -69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm,
-69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm,
-69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm
802.11ah (1MHz) -4.00 dBm, -12.00 dBm, -24.00 dBm, -60.00 dBm, -60.00 dBm, -
60.00 dBm, -60.00 dBm, -60.00 dBm, -60.00 dBm, -60.00 dBm, -
60.00 dBm, -60.00 dBm, -60.00 dBm, -60.00 dBm
802.11ah (2MHz) -4.00 dBm, -12.00 dBm, -24.00 dBm, -63.00 dBm, -63.00 dBm, -
63.00 dBm, -63.00 dBm, -63.00 dBm, -63.00 dBm, -63.00 dBm, -
63.00 dBm, -63.00 dBm, -63.00 dBm, -63.00 dBm
802.11ah (4MHz) -4.00 dBm, -12.00 dBm, -24.00 dBm, -66.00 dBm, -66.00 dBm, -
66.00 dBm, -66.00 dBm, -66.00 dBm, -66.00 dBm, -66.00 dBm, -
66.00 dBm, -66.00 dBm, -66.00 dBm, -66.00 dBm
802.11ah (8MHz/16MHz) -4.00 dBm, -12.00 dBm, -24.00 dBm, -69.00 dBm, -69.00 dBm, -
69.00 dBm,-69.00 dBm, -69.00 dBm, -69.00 dBm,-69.00 dBm, -
69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm
802.11j/p (10MHz) -4.00 dBm, -12.00 dBm, -24.00 dBm, -60.00 dBm, -60.00 dBm, -
60.00 dBm, -60.00 dBm, -60.00 dBm, -60.00 dBm, -60.00 dBm, -
60.00 dBm, -60.00 dBm, -60.00 dBm, -60.00 dBm
802.11j/p (5MHz) -4.00 dBm, -12.00 dBm, -24.00 dBm, -57.00 dBm, -57.00 dBm, -
57.00 dBm, -57.00 dBm, -57.00 dBm, -57.00 dBm, -57.00 dBm, -
57.00 dBm, -57.00 dBm, -57.00 dBm, -57.00 dBm
802.11af (6MHz) -4.00 dBm, -12.00 dBm, -24.00 dBm, -66.00 dBm, -66.00 dBm, -
66.00 dBm, -66.00 dBm, -66.00 dBm, -66.00 dBm, -66.00 dBm, -
66.00 dBm, -66.00 dBm, -66.00 dBm, -66.00 dBm
802.11af (7MHz) -4.00 dBm, -12.00 dBm, -24.00 dBm, -66.00 dBm, -66.00 dBm, -
66.00 dBm, -66.00 dBm, -66.00 dBm, -66.00 dBm, -66.00 dBm, -
66.00 dBm, -66.00 dBm, -66.00 dBm, -66.00 dBm
802.11af (8MHz) -4.00 dBm, -12.00 dBm, -24.00 dBm, -66.00 dBm, -66.00 dBm, -
66.00 dBm, -66.00 dBm, -66.00 dBm, -66.00 dBm, -66.00 dBm, -
66.00 dBm, -66.00 dBm, -66.00 dBm, -66.00 dBm
WLAN Mode Auto Function Presets
Radio Std Presets
802.11a/g (OFDM/DSSS-OFDM)
802.11n (20MHz/40MHz)
OFF, OFF, OFF, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON, ON
