Electric vehicle guide
282
Portable charge
Portable charge
1
Code and Plug (Code set)
2
Control Box
3
Charging Cable and Charging Con
-
nector
Portable Charge can be used when AC
Charge or DC Charge is not available by
using household electricity.
Setting the charge level of the
portable charger
僅A: Plug
僅B: Electric Outlet
1. Check the rated current of the electric
outlet prior to connecting the plug to
the outlet.
2. Connect the plug to a household elec
-
tric outlet.
3. Check the display window on the con
-
trol box.
4. Press the button (1) on the back of the
control box for 2 to 8 seconds to
adjust the charge level. (Refer to
charging cable type and example for
setting the charge level.)
5. The charge level on the display win
-
dow of the control box changes every
time you press the button (1).
6. When setting the charge level is com
-
plete, start charging according to the
portable charge procedure.
