Specifications & Consumer information
29
Dimensions
Specifications & Consumer information
Dimensions
Electric vehicle specifications
OBC: On-Board Battery Chargers
Volume and weight
Item mm (in)
Overall length
Type A 4,680 (184.3)
Type B (GT-Line) 4,695 (184.8)
Overall width
Type A 1,880 (74.0)
Type B (GT-Line) 1,890 (74.4)
Overall height 1,550 (61.0)
Tread
Front
235/55 R19 1,628 (64.1)
255/45 R20 1,623 (63.9)
Rear
235/55 R19 1,637 (64.4)
255/45 R20 1,632 (64.3)
Wheelbase 2,900 (114.2)
Items
Standard type Extended type
2WD 4WD 2WD 4WD
Motor
Max. output (kW)
Front - 53 - 74
Rear 125 120 168 165
Max. torque (Nm)
Front - 255 - 255
Rear 350 350 350 350
Battery
(Lithium-ion)
Capacity (kWh) 58 77.4
Power output (kW) 195 253
Voltage (V) 523 697
Charger (OBC) Max. output (kW)
AC single
phase
7 7
AC 3 phase 10.5 10.5
Region Type
Gross Vehicle Weight Luggage Volume
Standard range Extended range Min. Max.
Except Australia, New Zealand
2WD 2,340 kg (5,159 lbs.) 2,425 kg (5,357 lbs.)
STD: 520 l
(18.4 cu ft)
OPT: 490 l
(17.3 cu ft)
1300 l (45.9
cu ft)
4WD 2,445 kg (5,390 lbs.) 2,530 kg (5,578 lbs.)
For Australia, New Zealand
2WD 2,370 kg (5,225 lbs.) 2,455 kg (5,412 lbs.)
4WD 2,475 kg (5,456 lbs.) 2,560 kg (5,643 lbs.)
