Your vehicle at a glance
103
Motor room compartment
Motor room compartment
* The actual motor compartment in the vehicle may differ from the illustration.
1. Coolant reservoir 8-9
2. Brake fluid reservoir 8-9
* This part is located on the opposite side for Right-hand drive vehicle.
3. Windshield washer fluid reservoir 8-10
4. Fuse box 8-22
5. Negative battery terminal (-) 8-13
6. Positive battery terminal (+) 8-13
7. Front trunk 5-33
