4-5.2.3 Distance Pipe Installation
In systems where there is an odd number of cylinders, use a distance pipe (80L P/N 03-8331-
0000) to ensure the lone cylinder is held properly in the wooden bracket. The distance pipe is a sheath
that goes over the clamping bolt.
Figure 4-7. Installed Distance Pipe
Distance Pipe
