8-9 DISCHARGE NOZZLES
Note: For the full listed NPT nozzles with corresponding orifice areas, see Table 8-10 and
Table 8-12. For the full listed BSP nozzles with corresponding orifice areas, see Table 8-
11 and Table 8-13.
WARNING
Only listed Kidde IGS nozzles are to be used on Kidde Inert Gas Systems. Failure
to comply with this WARNING can result in unpredictable Agent distribution.
Table 8-9. Kidde IGS Nozzle Part Numbers
Description Part Number
NPT Nozzles
Nozzle Assembly, 1/2" NPT, 360° 38-407100-XXX
Nozzle Assembly, 3/4" NPT, 360° 38-407200-XXX
Nozzle Assembly, 1" NPT, 360° 38-407300-XXX
Nozzle Assembly, 1-1/2" NPT, 360° 38-407400-XXX
Nozzle Assembly, 1/2" NPT, 180° 38-407500-XXX
Nozzle Assembly, 3/4" NPT, 180° 38-407600-XXX
Nozzle Assembly, 1" NPT, 180° 38-407700-XXX
Nozzle Assembly, 1-1/2" NPT, 180° 38-407800-XXX
BSP Nozzles
Nozzle Assembly, 1/2" BSP, 360° 38-417100-XXX
Nozzle Assembly, 3/4" BSP, 360° 38-417200-XXX
Nozzle Assembly, 1" BSP, 360° 38-417300-XXX
Nozzle Assembly, 1-1/2" BSP, 360° 38-417400-XXX
Nozzle Assembly, 1/2" BSP, 180° 38-417500-XXX
Nozzle Assembly, 3/4" BSP, 180° 38-417600-XXX
Nozzle Assembly, 1" BSP, 180° 38-417700-XXX
Nozzle Assembly, 1-1/2" BSP, 180° 38-417800-XXX
