Component Descriptions
April 2020 2-40 06-237619-001
2-11.6 Clamping Bolt
Bolt used to connect the front clamping bar to the Unistrut rail. Clamping bolt comes with rel-
evant nuts and washers.
Figure 2-50. Clamping Bolt
2-11.7 Endcover
Use an endcover on each edge of the unistrut rail to protect the edge.
Figure 2-51. End Cover
Table 2-35. Kidde IGS Clamping Bolt Part Numbers
Part Number Description
01-8337-0200 Clamping Bolt, 2 Row, 80L - 28.2” (715 mm Long)
01-8337-0300 Clamping Bolt, 3 Row, 80L - 40.6” (1030 mm) Long
Table 2-36. Kidde IGS End Cover Part Numbers
Part Number Description
01-8131-0002 Endcover, White PVC
