Component Descriptions
06-237619-001 2-41 April 2020
2-11.8 Distance Pipe
Use the distance pipe as a spacer when the front row of a cylinder rack has less cylinders than
the rear row of the rack. Distance Pipes are only used on multi-row systems.
Figure 2-52. Distance Pipe
Figure 2-53. Installed Distance Pipe
Table 2-37. Kidde IGS Distance Pipe Part Numbers
Part Number Description
03-8331-0000 Distance Pipe 3/4" + Washers 80L
Distance Pipe
