Component Descriptions
April 2020 2-16 06-237619-001
2-4.9 Odorizer Assembly
The odorizer assembly, P/N 81-897600-000, injects a scent of wintergreen into the agent
during a discharge. Upon discharge, the agent pressure ruptures a burst disc to release the
scent of wintergreen. This scent warns personnel in the vicinity of the area protected by the
fire suppression system that agent is present.
Figure 2-20. Odorizer Assembly
8.7” REF
2.0” REF
3/4” NPT
CONNECTION
