Component Descriptions
06-237619-001 2-35 April 2020
2-10 MANIFOLD EQUIPMENT
Manifolds are available in single and double row configurations. Manifolds can be coupled
together using the 2” BSP Manifold Coupling (P/N:
38-400020-100). Cylinder capacity must match
the selected manifold to ensure proper offset location.
Table 2-27. Kidde IGS Manifold Equipment Part Numbers
Part Number Description
38-351000-004 80 Liter 2 Stub 1 Row 2" Manifold BSP, with 2 manifold check valves
38-351000-005 80 Liter 3 Stub 1 Row 2" Manifold BSP, with 3 manifold check valves
38-351000-006 80 Liter 4 Stub1 Row 2" Manifold BSP, with 4 manifold check valves
38-351000-007 80 Liter 5 Stub 1 Row 2" Manifold BSP, with 5 manifold check valves
38-351000-008 80 Liter 6 Stub 1 Row 2" Manifold BSP, with 6 manifold check valves
38-351000-009 80 Liter 4 Stub 2 Row 2" Manifold BSP, with 4 manifold check valves
38-351000-010 80 Liter 6 Stub 2 Row 2" Manifold BSP, with 6 manifold check valves
38-351000-011 80 Liter 8 Stub 2 Row 2" Manifold BSP, with 8 manifold check valves
38-400020-100 2" BSP Manifold Coupling
38-400020-101 2" BSP Manifold End Cap
38-400020-102 3/4" BSP Manifold End Cap For 14mm Check Valve
