Kidde IG-55 - Page 196

Parts List
April 2020 8-12 06-237619-001
13 132.7323 0.2057 38-417600-130 38-417700-130
13.5 143.1388 0.2219 38-417600-135 38-417700-135
14 153.9380 0.2386 38-417600-140 38-417700-140 38-417800-140
14.5 165.1300 0.2560 38-417700-145 38-417800-145
15 176.7146 0.2739 38-417700-150 38-417800-150
15.5 188.6919 0.2925 38-417700-155 38-417800-155
16 201.0619 0.3116 38-417700-160 38-417800-160
16.5 213.8246 0.3314 38-417700-165 38-417800-165
17 226.9801 0.3518 38-417700-170 38-417800-170
17.5 240.5282 0.3728 38-417700-175 38-417800-175
18 254.4690 0.3944 38-417700-180 38-417800-180
18.5 268.8025 0.4166 38-417800-185
19 283.5287 0.4395 38-417800-190
19.5 298.6477 0.4629 38-417800-195
20 314.1593 0.4869 38-417800-200
20.5 330.0636 0.5116 38-417800-205
21 346.3606 0.5369 38-417800-210
21.5 363.0503 0.5627 38-417800-215
22 380.1327 0.5892 38-417800-220
22.5 397.6078 0.6163 38-417800-225
23 415.4756 0.6440 38-417800-230
23.5 433.7361 0.6723 38-417800-235
24 452.3893 0.7012 38-417800-240
24.5 471.4352 0.7307 38-417800-245
25 490.8739 0.7609 38-417800-250
25.5 510.7052 0.7916 38-417800-255
26 530.9292 0.8229 38-417800-260
Table 8-13. Kidde IGS Listed 180 BSP Degree Nozzles (Continued)
Orifice
Diameter
(mm)
Area Orifice Area
mm
2
in.
2
0.5” 0.75” 1.00” 1.50”
