TERRA 4K Operation Manual（KineOS 6.2）
©2019 Kinefinity Inc. Page 27 / 60
3.4 Custom LUT
TERRA supports custom LUT perfectly: from shooting to post with custom
LUT. There is one in-camera preset LUT: KC_Neut. KC_Neut has more accurate
highlight and details in shadow than Kine709 and covers balanced tone with
normal saturation and contrast.
You can upload a LUT to TERRA, switch different LUT/Look instantly when
monitoring. While record cDNG or ProRes with custom LUT; it does not get
burned into the footage: RAW is RAW, on-site LUT for monitoring is dumped
to clip folder, and can be used by the editor for a quick grade.
You can upload 3
rd
-partyLUT to the camera as many as you want; supporting
up to 33x33x33 3D LUT Cube, SCRATCH and DaVinci Resolve can output
cube LUT.
3.4.1 Upload Custom LUT
It just needs three simple steps:
1. Output from DI software and rename it, rename the LUT into four
letters in English, like CAN1.cube;
2. Copy the LUT into root folder of USB stick as FAT/FAT32;
3. Upload to TERRA: insert USB stick to USB port:
[ConfigurationLUTLoad Custom LUT]; it only takes one second.
Reboot the camera, and the new LUT will be shown in the LUT
shortcut list if press [Multifunction Wheel  Right Button].
NOTE The LUT will be overwritten, if the name is same, and there
should be no blank in the name and not more than four letters.
3.4.2 Erase Custom LUT
Erasing the uploaded custom LUT is also intuitive,
[ConfigurationLUTClean Custom LUT]
Then all custom LUT will be deleted in a second, and only native KC_Neut will
be remained.
Menu Operation
Load Custom LUT
[ConfigurationLUT
Load Custom LUT]
Menu Operation
Erase custom LUT
[ConfigurationLUT
Clean Custom LUT]
