3.10 Anamorphic Lens Support And 4:3 Recording
Anamorphic was a technical choice for filming, but now an aesthetic
preference. Echo to more affordable anamorphic lenses, TERRA 4K, MAVO
and MAVO LF are now also good choices for anamorphic shooting, as the
CMOS imaging sensors are all 3:2. For TERRA 4K:
4:3 anamorphic: 3700x2700; with 2x anamorphic lens, the desqueezed
resolution is 7400x2700;
Open Gate: 4096x2700, all pixels of the CMOS imaging sensor are
captured, leave maximum room for post processing.
Under 4:3 anamorphic and Open Gate, frame rate up to 50fps support 2x,
1.8x, 1.75x, 1.5x, 1.33x, 1.25x, 0.5x anamorphic shooting, which falls into
almost all anamorphic lenses in the market.
When use 2x anamorphic lens:
De-squeezed image means images are recovered from 2:1 anamorphic lens.
It gets clips with amazing 7.4K resolution, and downscale to 4K and 2K in
post workflow.
For monitoring when shooting at 4:3 with anamorphic lens, you can de-
squeeze the images into normal image by setting anamorphic lens factor in
Configuration menu. For example, anamorphic lens factor is 2, set the factor
in camera to 2, then you can get normal view of 7.4K CinemaScope, not
squeezed image by lens.
Set the ratio: [ConfigurationLiveview Anamorphic Lens]
NOTE The recorded clips are 4:3 instead of de-squeezed and
monitoring depends on the ratio you set. To get normal
monitoring, you need to set de-squeeze factor to match lens,
but the actual clips are still 4:3.
Menu Operation
Set Anamorphic Lens
[ConfigurationLiveview
Anamorphic Lens]
