Kinoton FP 38 E Premiere - Other Electrical Components in the Projector Console; Rectifiers


Components
Issue: 08/2012

 
 X1 main terminal strip
Á Internal terminal strip with main fuse 6.3 A
 Relays: RUN, C/O, XENON
à Mains contactor
Ä Fuse 10 A
Å Overload release 40 A
 Interface board
 Mains lter
 Current at make limiter
 LED power supply board
Error I/O board for pager system (option)
The  can be designed for analog
and digital sound LED’s supply or for analog
LED’s supply only.
The LED board is powered via the projector
with 24 V.
 
The rectier supplies the xenon lamp with regular current. The needed intensity of
currents for the rectier (type) depends on the xenon unit.

The rectier is placed in the console.
The standard rectier are available
with power of:
- 65 to 85 A
- 75 to 95 A
- 100 to 140 A
The intensity of current for the xenon
lamp is adjustable by turning the hand
wheel on the projector housing - the
rectier iron core will be moved. The
adjusted intensity of current is dis-
played on the ammeter.
3
1
4
6
7
8
9
10
11
2
5
