Kinoton FP 38 E Premiere - Main Board Components Overview


Parts and Wearing Parts
Issue: 08/2012

 
 
Ø 9 mm, 600 m lm 0040 060 00050
Ø 12,7 mm, 1800 m lm 0040 060 00765
Ø 12,7 mm, 2000 m lm 0040 060 00770
 
 
Ø 12.7 mm (USA)
1000 535 77055
Ø 12.7 mm
1000 535 77054
Ø 9 mm
1000 535 77053
 
 
Pilot lamp, 24 V / 3 W 0040 120 00059
Key lamp 1000 134 87005
Fuse 6.3 AT 4822 253 30031
 
 
Triple aperture shaped 1000 451 17012
Triple aperture for ling 1000 451 17016
Hole aperture to adjust the frame center 1000 451 17017
Triple aperture dimension smaller than specied 1000 451 17020
Hole aperture for ling 1000 451 17022
 
 
Single aperture complete CS 2.35:1 5322 451 10009
Single aperture complete NS 1.37:1 5322 451 10011
Single aperture complete 1.85:1 5322 451 10012
Single hole aperture complete 5322 451 10013
Single aperture for silent movies 1000 451 17014
Single aperture complete Super 35 mm 1000 451 17015
Single aperture nished size 1:1.37 1000 451 17023
Single aperture nished size 1:1.66 1000 451 17024
Single aperture nished size 1:1.85 1000 451 17030
Single aperture nished size 1:2.39 1000 451 17034
Single aperture S35/1:2.39 1000 451 17029
Single aperture CS+1:1.66 1000 451 17031
Single aperture S35/1.1.85 1000 451 17032
Single aperture S35/CS 1000 451 17033
