Parts and Wearing Parts
Issue: 08/2012

 
 
  
Film runner strip, white
Film runner strip, Novotex brown
 1000 463 17005
1000 463 17013
Knurled screw for lm runner strip fastening  5322 505 10336
Ceramics roller  5322 532 50362
Film pressure skate black  1000 463 17020
 
  
Film stripper for feed and bottom sprocket

1000 404 57008
Pad shoe

5322 525 30003
Nut for pad shoe

5322 462 50027
Spring for pad shoe

5322 492 40001
Hand wheel bottom sprocket 1000 413 47002
 
  
Large guide roller Ø 34 mm
Cap


1000 525 37042
5322 462 70374
Guide roller Ø 20 mm
Cap


1000 525 67054
5322 462 70373
Guide roller with ball bearing and stay roller
 1000 525 37041
Guide roller with ball bearing
 1000 525 67028
Guide roller support with 2 shafts 1000 404 57065
 
  
Knurled screw for shutter housing  5322 505 10192
Focusing knob  1000 413 37001
Skate pressure adjusting knob  1000 413 37001
Knurled screw for lens fastening (M 4 x 8)  1000 502 17004
Film cleaner 0040 060 0048X
