Issue: 08/2012
X
Z The xenon lamp will be switched on when the lm is running forwards (DIP 7 is
OFF).
If DIP 7 is ON the xenon lamp will ignite at the rst projector start and will get off
when projector is switched off.
Z The dowser will be open when projection speed is more than zero.
Z All switching and direction changes are to be done when projector is off.
Start forwards
Press “in” selects 25 fps (factory-set) - press “out” selects 24 fps (factory-set)
Stop the forward or optional reverse running
Start reverse (optional for projectors with reverse running unit)
Select 24 fps or VARIA speed (optional)
• To start press
.
• Press “in”
to select the speed of 25 frames/seconds (factory-set), press “out” to
select the speed of 24 frames/seconds (factory-set).
• Pushing
you can stop the forward running of projector.
• To start press
.
• Pushing
you can stop the reverse running of projector.
X
The reverse running speed is factory-set (in frequency inverter).
