Repair and Adjustments
Issue: 06/2011
X
Z Read the data sheet which is delivered with xenon bulb. The bulb manufacturer’s
own data should be used.
Z Read also rectier’s operating manual.
The intensity of currents associated to the installed xenon bulb can be adjusted on the
rectier. The control can be operated by a potentiometer, a hand wheel, bridges, etc.
1000 50 55
1600 65 70
2000 70 85
2500 90 100
3000 100 110
4000 135 150
5000 140 150
7000 160 165
A magnet stabilizes the arc between cathode and anode. An even well adjusted light
arc provides a good optical efciency and increase the life of the xenon lamp.
S An adjustment can only be carried out by service personnel.
S An adjustment can only be carried out when xenon lamp is on. Therefore this
adjustment requires special protective equipment.
S Adjustment must be carried out with a special welders’ mask and suitable protective
equipment.
