Issue: 08/2012
Ceramics roller Remove the ceramics rollers and then remove the dirt in the
holes by using air pressure. Clean the ceramics roller with a
alcohol moisturized cloth.
Film break sensor Clean the lm break sensor with a soft cloth.
Main drive motor / fan Blow out the dust with pressurized air.
Guide rollers Clean the guide rollers and roller shafts with alcohol.
Spool shafts Lubricate with Esso universal oil.
Shutter /
shutter housing
Clean the shutter housing with pressurized air.
Clean shutter edges with a soft toothbrush.
Lens turret (if existing) Clean the coding plates and the sensors on the sensor board
with a Q-tip moisturized with Isopropyl or Isopropanol.
Do not blow with pressurized air into the rotor - particles can be blown into the rotor and
block the rotation.
