GENERAL
1-17
S196-WOO Jul. 2003
F. CLEANING GRILL, RADIATOR SCREEN AND
OIL COOLER SCREEN
(1) Radiator Screen
(A) DETACH
CK20H
(1) Radiator Screen
(2) Oil Cooler Screen
(A) DETACH
1. Check front grill and side screens to be sure they
are clean of any debris.
2. Detach the screen and eliminate all the foreign
material.
196W116A
196W117A
CK20
D. CHECKING HEAD LIGHT, HAZARD LIGHT
ETC.
1. Inspect the lights for broken bulbs and lenses.
2. Replace if broken.
E. CHECKING SEAT BELT AND ROPS
1. Always check condition of seat belt and ROPS at-
taching hardware before operating tractor.
2. Replace if damaged.
To avoid personal injury:
• Be sure to stop the engine before removing the
screen.
CAUTION
• Grill and screen must be clean from debris to
avoid engine from overheating and to allow good
air intake for the air cleaner.
IMPORTANT
To Next Page
