GENERAL
1-35
S196-WOO Jul. 2003
9.10 SERVICE AS REQUIRED
A. BLEEDING FUEL SYSTEM
Air must be removed:
1. When the fuel filter or lines are removed.
2. When tank is completely empty.
3. After the tractor has not been used for a long period
of time.
Bleeding procedure is as follows:
1. Fill the fuel tank with fuel, and open the fuel cock.
2. Open the air vent cock on the fuel injection pump.
3. Start the engine and run for about 30 seconds, and
then stop the engine.
4. Close the air vent cock.
(1) Fuel Cock (A) Close
(B) Open
(1) Split Pin Plugs
B. DRAINING CLUTCH HOUSING WATER
The tractor is equipped with split pin plug under the
clutch housing.
After operating in rain, snow or tractor has been
washed, water may get into the clutch housing. Check
it by pushing in the split pin.
If water enters into the clutch housing, remove the plug
and drain the water, then install the plug again.
196W153A
196W154A
C. REPLACING LIGHT BULB
1. Head lights and rear combination lights:
Take the bulb out of the light body and replace with
a new one.
2. Other lights:
Detach the lens and replace the bulb.
Capacity
Light
35 W / 35 W
10 W
21 W
21 W
21 W
3.4 W
Head lights
Tail lights
Stop lights
Turn signal lights
Work light (Option)
Instrument panel light
1
2
3
4
5
6
• Always close the air vent cock except for bleed-
ing fuel lines.
• Otherwise, engine runs irregularly or stalls
frequently.
IMPORTANT
CK20-USA
Capacity
Light
55 W / 60 W
21 W
21 / 5 W
21 W
21 W
3.4 W
Head lights
Front Position lights
Stop / Rear Position lights
Turn signal lights
Work light
Instrument panel light
1
2
3
4
5
6
CK20-EU
