GENERAL
1-41
S196-WOO Jul. 2003
11. IMPLEMENT LIMITATIONS
The KIOTI tractor has been thoroughly tested for proper performance with implements sold or approved by KIOTI.
Use with implements which are not sold or approved by KIOTI and which exceed the maximum specifications
listed below, or which are otherwise unfit for use with the KIOTI tractor may result in malfunctions or failures of the
tractor, damage to other property and injury to the operator or others. [Any malfunctions or failures of the tractor
resulting from use with improper implements are not covered by the warranty.]
CK20
CK20H
Front
910 mm (35.8 in.)
Rear
940 mm (37 in.)
CK20
CK20H
Implement weight W1 and / or size
As in the following list
(shown on the next page)
Max. Drawbar Load W2
250 kg
(551 lbs.)
Tread (max. width)
Actual figures
Lifting capacity max.
loading weight
(24 in. aft of hitch)
1,109 lbs.
(503 kg)
Trailer loading weight
W
3
Max. capacity
812 kg
(1,792 lbs.)
Lifting capacity max. loading weight......... The max. allowable load which can be put on the 24 in. aft of hitch : W
0
Implement weight ....................................... The implement’s weight which can be put on the lower link : W
1
Max. drawbar load....................................... W
2
Trailer loading weight ................................ The max. loading weight for trailer (without trailer’s weight) : W
3
NOTE:
Implement size may very depending on soil operating conditions.
196W165A
Item
Model
Item
Model
To Next Page
