KIP 660 - Page 33

Chapter 2 Basic Operations 2-8
5. Turn down the lever (4) in either way until they completely stop, which lets the Flange to surely
hold the roll media.
6. Fit both Flanges correctly into both Slide Guides (5) in the roll deck.
(See next page for more explanation)
4
4
5
