Kipor IG2000 Shop Manual

30
4.4 Spark plug
Inspection/Cleaning:
1) Remove the spark plug cap and remove the spark plug.
2) Remove carbon or other deposits with a plug cleaner or stiff ire brush. Check the sealing
washer for damage.
3) Measure the plug resistance; replace the spark plug if the measure is not accordance with the
specification.
Spark plug resistance 3~9KΩ
4) Measure the plug gap with a feeler gauge. Adjust by bending the side electrode if the reading is
not within the specification..
Spark plug clearance 0.6~0.7mm
Standard spark plug UR5
© 2011 Kipor Power Systems, Inc.

Kipor IG2000 Specifications

General

Rated Power	1.6 kW
Voltage	230 V
Frequency	50 Hz
Fuel Type	Gasoline
Starting System	Recoil
Weight	22 kg
Engine Type	4-stroke, OHV
Noise Level	54-59 dB(A)
Continuous Operation Time	4 h (at rated load)
