1.2 PERFORMANCE CHARACTERISTICS
Model All
Maximum output AC 2.0KVA
Rated output AC 1.6KVA
Rated output DC 100W
Rated frequency 60HZ
Rated voltage AC 120V
Rated voltage DC 12V
Rated current AC 13.3A
Rated current DC 8.3A
Power factor 1.0
Voltage variation rate Momentary
Average
Average time
10% max
1.5% max
3 sec max
Voltage stability ±1%
Frequency variation rate Momentary
Average
Average time
1% max
1% max
1 sec max
Frequency stability ±0.1%
Insulation resistance 10 MΩ min
AC circuit protector 17.9A @120V
DC circuit protector 10A
Fuel tank capacity gal (L) .9 (3.5 )
Operating hours (at rated load) 4
Noise level NL-FL @23’ (7 m) 54-59
