Kipor IG2000 Shop Manual

31
0.6-0.7
5). Install the plug finger tight to seat the washer, then tighten with a plug wrench.
Torque valve is 13~15 N.m
4.5 Valve clearance
Caution
■ Valve clearance inspection and adjustment must be performed with the engine cold.
Inspection/Adjustment:
1) Remove the following parts:
―Front cover, control panel
―Rear cover
―Right/left side covers
―Fuel tank
―Inverter unit, engine bed
―Recoil starter, fan cover
―Inlet/Exhaust side baffle
2) Remove the four bolts and disassemble the cylinder cover. Don’t remove the valve cover with
excessive force or it will deform. Replace the valve cover if it is deformed.
© 2011 Kipor Power Systems, Inc.

Kipor IG2000 Specifications

General

Rated Power	1.6 kW
Voltage	230 V
Frequency	50 Hz
Fuel Type	Gasoline
Starting System	Recoil
Weight	22 kg
Engine Type	4-stroke, OHV
Noise Level	54-59 dB(A)
Continuous Operation Time	4 h (at rated load)
